KONE LCE230 ADO Board KM713160G01 713163H03 H04 H05 H06

KONE KM713160G01 is an LCE230 ADO/ACL safety-circuit board used in compatible KONE elevator control systems. The PCB may carry revision references such as 713163H03, 713163H04, 713163H05, or 713163H06.

In the elevator spare-parts market, this product is also described as:

• KONE LCEADO Board

• KONE LCE230 ADO Board

• KONE ADO/ACL Safety Circuit Board

• KONE KM713160G01

• KONE 713163H06

• KONE Elevator Safety Circuit PCB

• KONE LCE Control Board

Keep the Assembly Number and PCB Revision Together

The most useful identification reference is not only the name “LCE230.” Buyers should record the complete KM713160G01 assembly number together with the H-version printed on the circuit board.

Before ordering, please provide:

• KM713160G01 assembly label

• 713163H03, H04, H05, or H06 PCB marking

• LCEADO or ADO/ACL identification

• clear front and rear PCB photos

• connector and terminal arrangement

• installation position inside the controller

• elevator platform or controller model

• fault description

• previous repair information

• quantity required

The H03, H04, H05, and H06 markings belong to the same general board family, but they should not be treated as automatically interchangeable. Hardware revision, component layout, connector definition, or controller configuration may differ.

This board may be investigated when technicians encounter safety-circuit faults, unstable ADO-related signals, abnormal door-zone operation, damaged connectors, burned components, or other LCE controller problems. However, the PCB should not be diagnosed from the fault code alone.

Before replacing the board, technicians should also inspect the 230V supply, safety-circuit wiring, door-zone sensors, plugs, grounding, terminals, and related LCE modules. A field-wiring fault may produce symptoms similar to a defective board.

Some replacement-parts sources associate KM713160G01 with the later KM50006052G01 LCEADO assembly. Any replacement route should still be checked against the original controller, connectors, and site configuration before installation.

For maintenance companies in Saudi Arabia, Jordan, Egypt, Iraq, UAE, Kuwait, Brazil, Peru, Spain, and Italy, clear photos of the old board, complete H-version, connectors, and controller cabinet are recommended before shipment.

FAQ

Is KM713160G01 a standard LCE230 board?

It is more accurately described as an LCE230 ADO/ACL or LCEADO safety-circuit board rather than the basic LCE230 assembly.

Is 713163H06 the complete ordering number?

Usually not. KM713160G01 is commonly used as the assembly number, while 713163H06 or another H-version may be printed directly on the PCB.

Can H03, H04, H05, and H06 replace one another?

Not automatically. The original PCB revision, connector arrangement, component layout, and controller configuration should be compared first.

Can KM50006052G01 replace KM713160G01?

Some market references list KM50006052G01 as a later LCEADO replacement, but the controller version, wiring, connectors, and any required modification should be confirmed by a qualified technician before installation.
