Hyundai WB100 WBVF GATE 22-30KW Inverter Gate Board

The Hyundai WB100 WBVF GATE 22-30KW Inverter Gate Board is a power drive PCB used inside Hyundai elevator inverter systems. It is designed for the higher-power section of the WBVF drive range and is commonly associated with 22 kW and 30 kW inverter configurations.

Built for the Higher Power Range

This WBVF GATE board belongs to the inverter power control section rather than the elevator main controller.

A commonly documented identification is:

• Board type: WBVF GATE

• Power range: 22–30 kW

• Reference: CC-921

• Related board number: 20300532

• Application: Elevator inverter gate drive

Because Hyundai WB100/WBVF systems also use Gate Boards for lower power ratings, the inverter capacity should always be checked before selecting a replacement.

20300531 or 20300532?

These numbers should not be treated as the same board.

The 20300532 reference is commonly associated with the 22–30 kW WBVF GATE Board, while lower-power WB100 Gate Board applications may use a different board such as 20300531.

For replacement checking, please provide:

• WBVF GATE marking

• CC-921 or other reference number

• PCB number

• Inverter power rating

• Front and rear PCB photos

• Connector layout

• Complete inverter nameplate

• Required quantity

FAQ

What is Hyundai WBVF GATE 22-30KW used for?

It is used as an inverter gate drive and power module control board in Hyundai elevator drive systems.

Is CC-921 related to this Gate Board?

Yes. CC-921 is commonly associated with the Hyundai WBVF GATE 22–30 kW board.

Can a 5.5–15 kW WB100 Gate Board replace it?

No. The power range and board identification are different, so the original inverter capacity and PCB number should be matched before replacement.

For Hyundai WB100 WBVF GATE 22-30KW requirements, send us the original board photos and inverter nameplate for replacement checking before quotation.
