KONE Pit Inspection Station KM50090766G15 / KM50090766G22

KONE KM50090766G15 / KM50090766G22 is an elevator pit inspection station used for compatible KONE elevator maintenance and inspection work.

Installed in the elevator pit area, the inspection station provides technicians with local controls for inspection, testing, and maintenance operations. Depending on the version and system configuration, the box may include inspection buttons, an emergency stop switch, control switches, connectors, cables, and related safety-circuit connections.

The product may also be searched as:

• KONE KM50090766G15

• KONE KM50090766G22

• KONE Pit Inspection Station

• KONE Pit Inspection Box

• KONE Elevator Maintenance Box

• KONE KCE Pit Inspection Station

• Elevator Pit Control Box

G15 and G22 Version Checking

KM50090766G15 and KM50090766G22 belong to the same inspection-station product group, but the suffix should not be ignored. Different versions may vary in switch layout, cable length, plug arrangement, bypass configuration, wiring definition, or the elevator system in which they are installed.

Before ordering, technicians should compare the replacement unit with the original pit box and confirm:

• complete KM50090766G15 or KM50090766G22 label

• front-panel button and switch arrangement

• emergency stop switch type

• cable quantity and cable length

• plug and connector layout

• terminal and wiring configuration

• presence or absence of a bypass function

• installation position and mounting method

• elevator controller or KCE system information

The pit inspection station may require replacement when switches are damaged, the enclosure is broken, cables or connectors are worn, buttons fail to respond, or local inspection control becomes unstable. Because this unit is connected with elevator inspection and safety functions, installation and testing should be carried out by qualified elevator technicians.

When a fault remains after replacing the inspection box, the technician should also inspect the pit wiring, safety circuit, traveling cable connections, controller inputs, terminal plugs, and related inspection switches.

For maintenance companies in Saudi Arabia, Jordan, Egypt, Iraq, UAE, Brazil, Chile, Spain, and Italy, sending a complete old-box photo and connector details before quotation helps distinguish the G15 and G22 versions and reduces incorrect supply.
