Mitsubishi Power Supply Board CUS30-24

Mitsubishi Power Supply Board CUS30-24 is supplied for Mitsubishi elevator electrical control applications.

This product is normally requested by its exact model number rather than by a general description such as elevator power board or switching power supply. Because public technical documentation for CUS30-24 is limited, the original label, output specification, connector arrangement, and installation position should be confirmed before ordering.

Exact Model Identification

The primary model reference for this page is:

• CUS30-24
• Mitsubishi Elevator Power Supply Board CUS30-24
• Mitsubishi Switching Power Supply CUS30-24

For accurate supply, customers should provide a clear photo showing the complete CUS30-24 label.

The model should not be confused with CUS30-12, which is commonly listed together with Z59LX-83 as a Mitsubishi elevator power board with a 12V, 2.5A specification.

It should also not be confused with CUS30M-24. TDK-Lambda officially lists CUS30M-24 as a separate 24V, 1.25A, 30W AC-DC power supply model. The letter M is part of the model number and should not be ignored during replacement matching.

Information Needed for Correct Supply

Before ordering Mitsubishi Power Supply Board CUS30-24, please confirm:

• complete model number on the original unit
• rated output voltage
• rated output current
• connector quantity and position
• PCB or power supply dimensions
• mounting hole arrangement
• installation position inside the elevator system
• front, back, and label photos

This information helps avoid ordering a visually similar power supply with a different electrical specification.

Why Model Matching Matters

Elevator power supply boards may look similar while using different output voltages, currents, connectors, or wiring arrangements.

Selecting the wrong power supply may prevent the related elevator circuit from operating correctly or create additional electrical problems. For this reason, CUS30-24 should be matched by both the printed model number and the electrical information shown on the original label.

Quotation Reminder

Most inquiries for CUS30-24 can be confirmed faster when the buyer provides:

• a clear nameplate photo
• connector and wiring photos
• the elevator model or installation location
• the original power supply dimensions

If the label is unclear, please do not order based only on the product appearance.
